BATL
The Future of Civilian Night Vision Aiming
Toadworx’ flagship product - our Bispectral Aiming Tactical Laser (BATL).
Constructed of 6061 aluminum, steel, and reinforced with aerospace-grade epoxies, the BATL is engineered to withstand everything you can throw at it - and then some.
Tech Specs
The BATL in the stack
| Feature | Specification |
|---|---|
| Visible Power | 0.9mW (Class II) |
| Visible Div. | 0.5 mrad |
| IR Aiming Power | 0.9mW (Class II) |
| IR Aiming Div. | 0.5 mrad |
| Illum Power | 5mW (Class IIIR/IIIA) |
| Illum Div. | 5 and 10 deg via Flipcap |
| Housing | 6061-T6 Aluminum |
| Battery | CR123A |
| Mounting | MIL-STD 1913 Rail |
| Remotes | Crane-Style Plug |
| Weight | 218g without Battery |
| Recoil | 7.62 NATO + |
Join the Civilian Night Vision Revolution
FAQ
-
Yes. The BATL is designed as a Class 3a civilian-legal IR aiming device, meaning it meets all eye-safety requirements while providing maximum legal performance.
-
Every unit is designed and assembled in Wichita, KS. Over 70% of our parts are produced domestically.
-
Absolutely. Engineered by aerospace experts, the housing and internal subassemblies are ruggedized and co-aligned to ensure zero retention under the heavy recoil of modern sporting and tactical rifles.
-
Water-resistant. The BATL is designed to be IP67 rated for water and dust ingress; fully protected against dust and can withstand immersion in water up to 1 meter for 30 minutes.
-
Yes and no. The BATL uses a civilian legal <1mW aiming laser, which is visible beyond even practical night shooting distances. The illuminator is based on a 850mW LED and state-of-the-art diffuser and focuser technology, which is not subject to FDA regulations and provides a clean illuminator profile out to practical ranges of about 150m.
-
Unlike all of the defense contractors and their knockoffs, Toadworx appears to be the only company that has put user feedback and civilian and LEO use cases at the forefront of their development.
